Hub Type
No. of Grooves
Material
Belt Width
Bore (+.001 - .000)
Type
Pitch Dia.
Outside Dia.
Hub Dia.
Overall Length
There are 494 products.
| Part Number | Material | Pitch | No. of Grooves | Pitch Dia. | Outside Dia. | Flange O.D. | Hub Type | Belt Width | Type | Bore (+.001 - .000) | Face Width | Overall Length | Hub Proj. | Hub Dia. | Set Screws | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 20XL037-2A X 5/16 | Aluminum | 1/5 XL | 20 | 1.273 | 1.253 | NA | Set Screw | 0.3750 | 6 | 0.3125 | 0.5625 | 15/16 | 0.375 | 15/16 | 8-32(2) | |
| 20XL037-2A X 3/8 | Aluminum | 1/5 XL | 20 | 1.273 | 1.253 | NA | Set Screw | 0.3750 | 6 | 0.3750 | 0.5625 | 15/16 | 0.375 | 15/16 | 10-32(2) | |
| SAV-20XL025-1A X 1/4 | Aluminum | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Shaft Saver | 0.2500 | 6F | 0.2500 | 0.4375 | 0.750 | 0.3125 | 15/16 | 8-32(2) | |
| SAV-20XL025-1A X 5/16 | Aluminum | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Shaft Saver | 0.2500 | 6F | 0.3125 | 0.4375 | 0.750 | 0.3125 | 15/16 | 8-32(2) | |
| 20XL025-1A X 1/4 | Aluminum | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Set Screw | 0.2500 | 6F | 0.2500 | 0.4375 | 0.750 | 0.3125 | 15/16 | 8-32(2) | |
| 20XL025-1A X 5/16 | Aluminum | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Set Screw | 0.2500 | 6F | 0.3125 | 0.4375 | 0.750 | 0.3125 | 15/16 | 8-32(2) | |
| SAV-20XL037-1S X 1/4 | Steel | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Shaft Saver | 0.3750 | 6F | 0.2500 | 0.5625 | 0.875 | 0.3125 | 15/16 | 8-32(2) | |
| SAV-20XL037-1S X 5/16 | Steel | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Shaft Saver | 0.3750 | 6F | 0.3125 | 0.5625 | 0.875 | 0.3125 | 15/16 | 8-32(2) | |
| SAV-20XL037-1S X 3/8 | Steel | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Shaft Saver | 0.3750 | 6F | 0.3750 | 0.5625 | 0.875 | 0.3125 | 15/16 | 10-32(2) | |
| SAV-20XL037-1S X 1/2 | Steel | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Shaft Saver | 0.3750 | 6F | 0.5000 | 0.5625 | 0.875 | 0.3125 | 15/16 | 10-32(2) | |
| SAV-20XL037-1A X 1/4 | Aluminum | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Shaft Saver | 0.3750 | 6F | 0.2500 | 0.5625 | 0.875 | 0.3125 | 15/16 | 8-32(2) | |
| SAV-20XL037-1A X 5/16 | Aluminum | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Shaft Saver | 0.3750 | 6F | 0.3125 | 0.5625 | 0.875 | 0.3125 | 15/16 | 8-32(2) | |
| SAV-20XL037-1A X 3/8 | Aluminum | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Shaft Saver | 0.3750 | 6F | 0.3750 | 0.5625 | 0.875 | 0.3125 | 15/16 | 10-32(2) | |
| SAV-20XL037-1A X 1/2 | Aluminum | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Shaft Saver | 0.3750 | 6F | 0.5000 | 0.5625 | 0.875 | 0.3125 | 15/16 | 10-32(2) | |
| 20XL037-1S X 1/4 | Steel | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Set Screw | 0.3750 | 6F | 0.2500 | 0.5625 | 0.875 | 0.3125 | 15/16 | 8-32(2) | |
| 20XL037-1S X 5/16 | Steel | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Set Screw | 0.3750 | 6F | 0.3125 | 0.5625 | 0.875 | 0.3125 | 15/16 | 8-32(2) | |
| 20XL037-1S X 3/8 | Steel | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Set Screw | 0.3750 | 6F | 0.3750 | 0.5625 | 0.875 | 0.3125 | 15/16 | 10-32(2) | |
| 20XL037-1S X 1/2 | Steel | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Set Screw | 0.3750 | 6F | 0.5000 | 0.5625 | 0.875 | 0.3125 | 15/16 | 10-32(2) | |
| 20XL037-1A X 1/4 | Aluminum | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Set Screw | 0.3750 | 6F | 0.2500 | 0.5625 | 0.875 | 0.3125 | 15/16 | 8-32(2) | |
| 20XL037-1A X 5/16 | Aluminum | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Set Screw | 0.3750 | 6F | 0.3125 | 0.5625 | 0.875 | 0.3125 | 15/16 | 8-32(2) | |
| 20XL037-1A X 3/8 | Aluminum | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Set Screw | 0.3750 | 6F | 0.3750 | 0.5625 | 0.875 | 0.3125 | 15/16 | 10-32(2) | |
| 20XL037-1A X 1/2 | Aluminum | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Set Screw | 0.3750 | 6F | 0.5000 | 0.5625 | 0.875 | 0.3125 | 15/16 | 10-32(2) | |
| SAV-20XL037-5S X 1/4 | Steel | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Shaft Saver | 0.3750 | 3F | 0.2500 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| SAV-20XL037-5S X 5/16 | Steel | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Shaft Saver | 0.3750 | 3F | 0.3125 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| SAV-20XL037-5S X 3/8 | Steel | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Shaft Saver | 0.3750 | 3F | 0.3750 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| SAV-20XL037-5A X 1/4 | Aluminum | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Shaft Saver | 0.3750 | 3F | 0.2500 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| SAV-20XL037-5A X 5/16 | Aluminum | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Shaft Saver | 0.3750 | 3F | 0.3125 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| SAV-20XL037-5A X 3/8 | Aluminum | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Shaft Saver | 0.3750 | 3F | 0.3750 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| 20XL037-5S X 1/4 | Steel | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Set Screw | 0.3750 | 3F | 0.2500 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| 20XL037-5S X 5/16 | Steel | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Set Screw | 0.3750 | 3F | 0.3125 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| 20XL037-5S X 3/8 | Steel | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Set Screw | 0.3750 | 3F | 0.3750 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| 20XL037-5A X 1/4 | Aluminum | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Set Screw | 0.3750 | 3F | 0.2500 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| 20XL037-5A X 5/16 | Aluminum | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Set Screw | 0.3750 | 3F | 0.3125 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| 20XL037-5A X 3/8 | Aluminum | 1/5 XL | 20 | 1.273 | 1.253 | 1.500 | Set Screw | 0.3750 | 3F | 0.3750 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| SAV-21XL037-2A X 1/4 | Aluminum | 1/5 XL | 21 | 1.337 | 1.317 | NA | Shaft Saver | 0.3750 | 6 | 0.2500 | 0.5625 | 15/16 | 0.375 | 1.000 | 8-32(2) | |
| SAV-21XL037-2A X 5/16 | Aluminum | 1/5 XL | 21 | 1.337 | 1.317 | NA | Shaft Saver | 0.3750 | 6 | 0.3125 | 0.5625 | 15/16 | 0.375 | 1.000 | 8-32(2) | |
| 21XL037-2A X 1/4 | Aluminum | 1/5 XL | 21 | 1.337 | 1.317 | NA | Set Screw | 0.3750 | 6 | 0.2500 | 0.5625 | 15/16 | 0.375 | 1.000 | 8-32(2) | |
| 21XL037-2A X 5/16 | Aluminum | 1/5 XL | 21 | 1.337 | 1.317 | NA | Set Screw | 0.3750 | 6 | 0.3125 | 0.5625 | 15/16 | 0.375 | 1.000 | 8-32(2) | |
| SAV-21XL025-1A X 1/4 | Aluminum | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Shaft Saver | 0.2500 | 6F | 0.2500 | 0.4375 | 0.750 | 0.3125 | 1.000 | 8-32(2) | |
| SAV-21XL025-1A X 5/16 | Aluminum | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Shaft Saver | 0.2500 | 6F | 0.3125 | 0.4375 | 0.750 | 0.3125 | 1.000 | 8-32(2) | |
| 21XL025-1A X 1/4 | Aluminum | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Set Screw | 0.2500 | 6F | 0.2500 | 0.4375 | 0.750 | 0.3125 | 1.000 | 8-32(2) | |
| 21XL025-1A X 5/16 | Aluminum | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Set Screw | 0.2500 | 6F | 0.3125 | 0.4375 | 0.750 | 0.3125 | 1.000 | 8-32(2) | |
| SAV-21XL037-1S X 1/4 | Steel | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Shaft Saver | 0.3750 | 6F | 0.2500 | 0.5625 | 0.875 | 0.3125 | 1.000 | 8-32(2) | |
| SAV-21XL037-1S X 5/16 | Steel | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Shaft Saver | 0.3750 | 6F | 0.3125 | 0.5625 | 0.875 | 0.3125 | 1.000 | 8-32(2) | |
| SAV-21XL037-1A X 1/4 | Aluminum | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Shaft Saver | 0.3750 | 6F | 0.2500 | 0.5625 | 0.875 | 0.3125 | 1.000 | 8-32(2) | |
| SAV-21XL037-1A X 5/16 | Aluminum | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Shaft Saver | 0.3750 | 6F | 0.3125 | 0.5625 | 0.875 | 0.3125 | 1.000 | 8-32(2) | |
| SAV-21XL037-1A X 3/8 | Aluminum | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Shaft Saver | 0.3750 | 6F | 0.3750 | 0.5625 | 0.875 | 0.3125 | 1.000 | 10-32(2) | |
| 21XL037-1S X 1/4 | Steel | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Set Screw | 0.3750 | 6F | 0.2500 | 0.5625 | 0.875 | 0.3125 | 1.000 | 8-32(2) | |
| 21XL037-1S X 5/16 | Steel | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Set Screw | 0.3750 | 6F | 0.3125 | 0.5625 | 0.875 | 0.3125 | 1.000 | 8-32(2) | |
| 21XL037-1A X 1/4 | Aluminum | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Set Screw | 0.3750 | 6F | 0.2500 | 0.5625 | 0.875 | 0.3125 | 1.000 | 8-32(2) | |
| 21XL037-1A X 5/16 | Aluminum | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Set Screw | 0.3750 | 6F | 0.3125 | 0.5625 | 0.875 | 0.3125 | 1.000 | 8-32(2) | |
| 21XL037-1A X 3/8 | Aluminum | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Set Screw | 0.3750 | 6F | 0.3750 | 0.5625 | 0.875 | 0.3125 | 1.000 | 10-32(2) | |
| SAV-21XL037-5S X 1/4 | Steel | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Shaft Saver | 0.3750 | 3F | 0.2500 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| SAV-21XL037-5S X 5/16 | Steel | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Shaft Saver | 0.3750 | 3F | 0.3125 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| SAV-21XL037-5A X 1/4 | Aluminum | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Shaft Saver | 0.3750 | 3F | 0.2500 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| SAV-21XL037-5A X 5/16 | Aluminum | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Shaft Saver | 0.3750 | 3F | 0.3125 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| 21XL037-5S X 1/4 | Steel | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Set Screw | 0.3750 | 3F | 0.2500 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| 21XL037-5S X 5/16 | Steel | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Set Screw | 0.3750 | 3F | 0.3125 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| 21XL037-5A X 1/4 | Aluminum | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Set Screw | 0.3750 | 3F | 0.2500 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| 21XL037-5A X 5/16 | Aluminum | 1/5 XL | 21 | 1.337 | 1.317 | 1.5625 | Set Screw | 0.3750 | 3F | 0.3125 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| SAV-22XL025-1A X 1/4 | Aluminum | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Shaft Saver | 0.2500 | 6F | 0.2500 | 0.4375 | 0.750 | 0.3125 | 1.000 | 8-32(2) | |
| SAV-22XL025-1A X 3/8 | Aluminum | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Shaft Saver | 0.2500 | 6F | 0.3750 | 0.4375 | 0.750 | 0.3125 | 1.000 | 10-32(2) | |
| 22XL025-1A X 1/4 | Aluminum | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Set Screw | 0.2500 | 6F | 0.2500 | 0.4375 | 0.750 | 0.3125 | 1.000 | 8-32(2) | |
| 22XL025-1A X 3/8 | Aluminum | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Set Screw | 0.2500 | 6F | 0.3750 | 0.4375 | 0.750 | 0.3125 | 1.000 | 10-32(2) | |
| SAV-22XL037-1S X 1/4 | Steel | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Shaft Saver | 0.3750 | 6F | 0.2500 | 0.5625 | 0.875 | 0.3125 | 1.000 | 8-32(2) | |
| SAV-22XL037-1S X 5/16 | Steel | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Shaft Saver | 0.3750 | 6F | 0.3125 | 0.5625 | 0.875 | 0.3125 | 1.000 | 8-32(2) | |
| SAV-22XL037-1S X 3/8 | Steel | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Shaft Saver | 0.3750 | 6F | 0.3750 | 0.5625 | 0.875 | 0.3125 | 1.000 | 10-32(2) | |
| SAV-22XL037-1A X 1/4 | Aluminum | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Shaft Saver | 0.3750 | 6F | 0.2500 | 0.5625 | 0.875 | 0.3125 | 1.000 | 8-32(2) | |
| SAV-22XL037-1A X 5/16 | Aluminum | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Shaft Saver | 0.3750 | 6F | 0.3125 | 0.5625 | 0.875 | 0.3125 | 1.000 | 8-32(2) | |
| SAV-22XL037-1A X 3/8 | Aluminum | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Shaft Saver | 0.3750 | 6F | 0.3750 | 0.5625 | 0.875 | 0.3125 | 1.000 | 10-32(2) | |
| 22XL037-1S X 1/4 | Steel | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Set Screw | 0.3750 | 6F | 0.2500 | 0.5625 | 0.875 | 0.3125 | 1.000 | 8-32(2) | |
| 22XL037-1S X 5/16 | Steel | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Set Screw | 0.3750 | 6F | 0.3125 | 0.5625 | 0.875 | 0.3125 | 1.000 | 8-32(2) | |
| 22XL037-1S X 3/8 | Steel | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Set Screw | 0.3750 | 6F | 0.3750 | 0.5625 | 0.875 | 0.3125 | 1.000 | 10-32(2) | |
| 22XL037-1A X 1/4 | Aluminum | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Set Screw | 0.3750 | 6F | 0.2500 | 0.5625 | 0.875 | 0.3125 | 1.000 | 8-32(2) | |
| 22XL037-1A X 5/16 | Aluminum | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Set Screw | 0.3750 | 6F | 0.3125 | 0.5625 | 0.875 | 0.3125 | 1.000 | 8-32(2) | |
| 22XL037-1A X 3/8 | Aluminum | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Set Screw | 0.3750 | 6F | 0.3750 | 0.5625 | 0.875 | 0.3125 | 1.000 | 10-32(2) | |
| SAV-22XL037-2A X 1/4 | Aluminum | 1/5 XL | 22 | 1.401 | 1.381 | NA | Shaft Saver | 0.3750 | 6 | 0.2500 | 0.5625 | 15/16 | 0.375 | 1.0625 | 8-32(2) | |
| SAV-22XL037-2A X 5/16 | Aluminum | 1/5 XL | 22 | 1.401 | 1.381 | NA | Shaft Saver | 0.3750 | 6 | 0.3125 | 0.5625 | 15/16 | 0.375 | 1.0625 | 8-32(2) | |
| SAV-22XL037-2A X 3/8 | Aluminum | 1/5 XL | 22 | 1.401 | 1.381 | NA | Shaft Saver | 0.3750 | 6 | 0.3750 | 0.5625 | 15/16 | 0.375 | 1.0625 | 10-32(2) | |
| 22XL037-2A X 1/4 | Aluminum | 1/5 XL | 22 | 1.401 | 1.381 | NA | Set Screw | 0.3750 | 6 | 0.2500 | 0.5625 | 15/16 | 0.375 | 1.0625 | 8-32(2) | |
| 22XL037-2A X 5/16 | Aluminum | 1/5 XL | 22 | 1.401 | 1.381 | NA | Set Screw | 0.3750 | 6 | 0.3125 | 0.5625 | 15/16 | 0.375 | 1.0625 | 8-32(2) | |
| 22XL037-2A X 3/8 | Aluminum | 1/5 XL | 22 | 1.401 | 1.381 | NA | Set Screw | 0.3750 | 6 | 0.3750 | 0.5625 | 15/16 | 0.375 | 1.0625 | 10-32(2) | |
| SAV-22XL037-5S X 1/4 | Steel | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Shaft Saver | 0.3750 | 3F | 0.2500 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| SAV-22XL037-5S X 5/16 | Steel | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Shaft Saver | 0.3750 | 3F | 0.3125 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| SAV-22XL037-5A X 1/4 | Aluminum | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Shaft Saver | 0.3750 | 3F | 0.2500 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| SAV-22XL037-5A X 5/16 | Aluminum | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Shaft Saver | 0.3750 | 3F | 0.3125 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| 22XL037-5S X 1/4 | Steel | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Set Screw | 0.3750 | 3F | 0.2500 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| 22XL037-5S X 5/16 | Steel | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Set Screw | 0.3750 | 3F | 0.3125 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| 22XL037-5A X 1/4 | Aluminum | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Set Screw | 0.3750 | 3F | 0.2500 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| 22XL037-5A X 5/16 | Aluminum | 1/5 XL | 22 | 1.401 | 1.381 | 1.625 | Set Screw | 0.3750 | 3F | 0.3125 | 0.5625 | 0.5625 | NA | NA | 8-32(2) | |
| SAV-23XL037-1A X 1/4 | Aluminum | 1/5 XL | 23 | 1.464 | 1.444 | 1.6875 | Shaft Saver | 0.3750 | 6F | 0.2500 | 0.5625 | 0.875 | 0.3125 | 1.0625 | 8-32(2) | |
| 23XL037-1A X 1/4 | Aluminum | 1/5 XL | 23 | 1.464 | 1.444 | 1.6875 | Set Screw | 0.3750 | 6F | 0.2500 | 0.5625 | 0.875 | 0.3125 | 1.0625 | 8-32(2) | |
| SAV-23XL037-2A X 1/4 | Aluminum | 1/5 XL | 23 | 1.464 | 1.444 | NA | Shaft Saver | 0.3750 | 6 | 0.2500 | 0.5625 | 15/16 | 0.375 | 1.125 | 8-32(2) | |
| 23XL037-2A X 1/4 | Aluminum | 1/5 XL | 23 | 1.464 | 1.444 | NA | Set Screw | 0.3750 | 6 | 0.2500 | 0.5625 | 15/16 | 0.375 | 1.125 | 8-32(2) | |
| SAV-24XL025-1A X 1/4 | Aluminum | 1/5 XL | 24 | 1.528 | 1.508 | 1.750 | Shaft Saver | 0.2500 | 6F | 0.2500 | 0.4375 | 25/32 | 0.34375 | 1.0625 | 8-32(2) | |
| SAV-24XL025-1A X 5/16 | Aluminum | 1/5 XL | 24 | 1.528 | 1.508 | 1.750 | Shaft Saver | 0.2500 | 6F | 0.3125 | 0.4375 | 25/32 | 0.34375 | 1.0625 | 8-32(2) | |
| SAV-24XL025-1A X 3/8 | Aluminum | 1/5 XL | 24 | 1.528 | 1.508 | 1.750 | Shaft Saver | 0.2500 | 6F | 0.3750 | 0.4375 | 25/32 | 0.34375 | 1.0625 | 10-32(2) | |
| 24XL025-1A X 1/4 | Aluminum | 1/5 XL | 24 | 1.528 | 1.508 | 1.750 | Set Screw | 0.2500 | 6F | 0.2500 | 0.4375 | 25/32 | 0.34375 | 1.0625 | 8-32(2) | |
| 24XL025-1A X 5/16 | Aluminum | 1/5 XL | 24 | 1.528 | 1.508 | 1.750 | Set Screw | 0.2500 | 6F | 0.3125 | 0.4375 | 25/32 | 0.34375 | 1.0625 | 8-32(2) | |
| 24XL025-1A X 3/8 | Aluminum | 1/5 XL | 24 | 1.528 | 1.508 | 1.750 | Set Screw | 0.2500 | 6F | 0.3750 | 0.4375 | 25/32 | 0.34375 | 1.0625 | 10-32(2) |
